As an industrial-grade electrical switching device, YIJIA Relay with Lockable Test Button adds a manual test button and a locking structure on the basis of the core functions of a standard relay. It can be manually triggered for detection during installation, maintenance or troubleshooting without additional control signals, quickly verifying the operation status of the equipment. Its shell is made of engineering plastic, and the contacts are equipped with silver alloy materials, which have high conductivity and arc resistance, enabling stable operation under complex working conditions. At the same time, it has a built-in high-brightness LED status indicator to display the working status of the relay in real time, suitable for applications in industrial automation, safety systems, power distribution and other fields.
Core Functions & Design Highlights
YIJIA Relay with Lockable Test Button is equipped with a lockable test button, supporting toggle between manual test and locking mode. During testing, no external signal is required, which facilitates quick completion of equipment power-on and action verification, improving installation and maintenance efficiency. The locking function can prevent accidental pressing or activation by unauthorized personnel, avoiding equipment failures or safety risks caused by unintended operations, especially suitable for safety-critical systems to enhance operational safety.
The product contacts are made of lead-free and cadmium-free silver alloy, which balances high conductivity and arc resistance. Logic-level signal transmission is smooth, and it can stably connect and break under full-load working conditions. The shell is made of flame-retardant engineering plastic, complying with industrial safety standards, and is matched with irradiated high-temperature wires, which are halogen-free, low-smoke and low-toxic, suitable for long-term use in industrial environments. The power frequency withstand voltage between the coil and the contacts is above AC2200V, with excellent insulation performance, reducing the risk of leakage and short circuit.
It integrates a high-brightness LED indicator, which clearly distinguishes the pull-in and release status of the relay, facilitating on-site personnel to quickly identify the operation status. The inside of the socket adopts an integral connection structure, reducing assembly errors and improving the overall reliability of the equipment. Multiple contact specifications are available, supporting 2 groups, 3 groups and 4 groups of convertible contacts, adapting to different load and control needs. The rail mounting method is suitable for various control cabinets and distribution boxes, with convenient installation and space saving.
Application Scenarios
Industrial Automation Control
Suitable for PLC control systems of production lines, executive units of mechanical equipment, and signal switching of automated assembly lines. It can quickly complete equipment self-inspection and maintenance, reduce downtime, and ensure the continuous operation of the production line. YIJIA Relay with Lockable Test Button can adapt to the long-term stable operation needs of industrial automation equipment.
Safety Protection Systems
Used in fire emergency power supplies, security alarm devices, and industrial safety interlock systems. The locking mechanism avoids misoperation, ensures reliable operation of equipment in emergency situations, and improves the overall safety protection level. It is an essential component in safety-critical systems.
Power Distribution & Energy Management
Applied in distribution boxes, power distribution cabinets, and substation control circuits to realize power distribution, load switching and fault isolation. The stable electrical performance adapts to the long-term high-load operation needs of power distribution systems, ensuring the safety and stability of power supply.
HVAC & Building Control
Suitable for control modules of central air conditioning and industrial ventilation equipment, quickly responding to start-stop commands, and facilitating maintenance personnel to conduct regular inspections, reducing the operation and maintenance costs of building equipment.
Brand & Quality Assurance
YIJIA Industrial Electrical Co., Ltd. specializes in the R&D, production and sales of industrial control products. Its core products include relays, AC contactors, push button switches, signal lights and other series. With years of technical accumulation and international market experience, it has become a professional large-scale industrial control manufacturing enterprise in China.
The company is equipped with advanced production equipment and a modern management system, and has passed the ISO9001 international quality management system certification. The products have obtained multiple international certifications such as CCC, CE and RoHS, and the quality meets global industry standards. YIJIA adheres to independent R&D and technological innovation, continuously optimizes product performance. Its relay series are widely used in power control and mechanical operation control fields such as consoles, control cabinets, distribution boxes and instrument boxes, meeting the customized needs of customers in different industries.
Frequently Asked Questions (FAQ)
1. How to use the lockable test button?
First press the test button to trigger the relay action and verify the contact switching and indicator status. After the test is completed, fix the button position through the locking structure to prevent accidental pressing, and it can return to normal use after unlocking.
2. Which voltages and loads is the product compatible with?
The rated operating voltage is DC24V (common specification), suitable for resistive or inductive loads of AC250V/28VDC and maximum 15A. Specific models can be selected according to contact specifications and actual working conditions.
3. How to judge the working status of the relay?
The built-in LED indicator turns on and off synchronously with the pull-in/release of the relay, which can intuitively identify the working status. If the indicator is abnormal, the contact or coil fault can be quickly checked through the test button.
4. What is the environmental adaptability of the product?
The operating temperature ranges from -40℃ to +85℃, withstanding 45%–85% relative humidity. It also has vibration resistance and impact resistance, suitable for complex environments such as industrial sites and outdoor power distribution.
5. Does the product provide customized services?
It supports customization of basic parameters such as the number of contacts, coil voltage and installation method. It can be adjusted according to the customer's control cabinet layout and control needs to adapt to diverse application scenarios.
Procurement & Service
With stable quality, reasonable price and perfect after-sales service, YIJIA provides industrial control product procurement solutions for global customers, supporting batch customization and spot supply, adapting to various cooperation modes such as foreign trade orders and project procurement. For more information about product models, delivery cycles and certification details, please contact us to get an exclusive procurement plan. YIJIA Relay with Lockable Test Button is your reliable choice for industrial control product procurement.
Features & Benefits
● Pure copper coil
● Silver alloy contacts
● Up to 5A
● 2NO2NC/3NO3NC/4NO4NC
● Compact design
● High-quality plastic
● CCC,CE
● Support to button switch OEM/ODM
● Offer quality and low price product
How to select the appropriate type of metal push button
Please answer the following question, and send it to us, we will select the appropriate type for you.
Question&Example
① the dimensions of push button to install: 16mm.
② the load current you need to control: 5A.
③ the type of head part: plat head without light.
④ choose the contact structure: 1NO1NC/2NO2NC
⑤ Operation mode: Momentary or Latching.
⑥ LED volt and color(if need led): DC 24V GREEN.
⑦ choose the materials of shell: Stainless steel or Brass clad chromium.
⑧ special request: waterproof, Custom symbol, need socket...
